3 Freq 617-3800MHz Diplexer
3 Freq 617-3800MHz Diplexer
- HL-3F-100-0638-4310F -W
- Others
- 617-3800
● Wide Frequency Band
● 2G/3G/4G/5G Coverage
● Low Passive Intermodulation(-160dBc)
● Low VSWR & Insertion Loss
● Widely used for In-building Solutions
Model | HL-3F-100-0638-4310F -W | ||
Freq-MHz | CH1:617-960 | CH2:1710-2700 | CH3:3300-3800 |
Insertion loss-dB | ≤0.5 | ||
Rejection -dB | ≥50 | ||
VSWR | ≤1.3 | ||
PIM-dBc | ≤-160@2*43dBm | ||
Average Power-W | 100 | ||
Impedance-Ω | 50 | ||
Connector | 4.3-10 Female | ||
Temp(deg) | -10~+65 | ||
Humidity | 0%-95% | ||
Applications | IP65 | ||
Relative humidity | 5% - 95% | ||
