China VPol 500MHz 3-12dBi Omni Antennas wholesale supplier

  • VPol 500MHz 3-12dBi Omni Antennas
  • VPol 500MHz 3-12dBi Omni Antennas
VPol 500MHz 3-12dBi Omni Antennas Series
  • TQJ-500AT3/TQJ-500AT5/TQJ-500B/TQJ-500D/TQJ-500DII
  • Private Communication
  • Fiberglass Antenna
  • 300-800
  • 12
  • 360
  • Ver

TQJ-500AT3/TQJ-500AT5/TQJ-500B/TQJ-500D/TQJ-500DII
Applications
● 500MHz band
● Point to multipoint
● Wireless video system
● Wireless trunking system
● Wireless data transmission system

Model

TQJ-500AT3

 TQJ-500AT5

TQJ-500B

TQJ-500D

Freq.Ragne-MHz

480-590

500-590

480-590

480-590

Bandwidth-MHz

20

10

20

20

Gain-dBi

3

5

8

10.2

Ver.Beamwidth-°

50

28

16

10

VSWR

≤1.5

1.5

≤1.5

≤1.5

Impedance-Ω

50

50

50

50

Polarization

Vertical

Vertical

Vertical

Vertical

Max.Power-W

100

100

100

100

Connector

N male or customized

N Female

N female or customized

N female or customization

Length-m

0.6

1.2

2.5

4±0.2

Weight-Kg

0.35

 0.41

2.5

4.4±1

Mast Diameter-mm

φ30 to 50

φ40 to 50

φ40 to 50

φ40 to 50
