698-2700MHz Broadband Directional Antenna
698-2700MHz Broadband Directional Antenna
- TDJ-0727DSAL-M
- Indoor DAS
- Panel Antenna
- 698-2700
- 9.5
- 85
- Vertical
698MHz to 2700MHz broad band
Low VSWR
Support the popular communications system currently
Sealed with radome, Strong protection ability
Supplied with down-tilt bracket for mast mounting, a down-tilt bracket for wall mounting is optional
Model | TDJ-0727DSAL-M | ||||
Freq.Range-MHz | 698-806 | 806-960 | 1710- 2700 | ||
Beamwidth-º | E | 65 | 60 | 50 | |
| H | 85 | 85 | 60 | |
F/B Ratio-dB | ≥15 | ≥18 | ≥18 | ||
Gain-dBi | 7±0.5 | 8±0.5 | 9.5±1 | ||
VSWR | ≤1.5 | ||||
Impedance-Ω | 50 | ||||
Polarization | Vertical | ||||
IM3-dBm(33dBm) | ≤-107 | ||||
Max.Power-W | 100 | ||||
Connector | N female or customized | ||||
Dimensions（with bracket）-mm | 293×210×65 | ||||
Weight(without bracket)-Kg | 0.92 | ||||
Mast Diameter-mm | φ40 to 50 | ||||
Note:When installing, you should let the side with a little hole face down to prevent the antenna radome from water. | |||||
