China 806-960MHz gsm outdoor antenna customized quotes
- TDJ-XX0638BJB-MY
- 617-697/698-960/1710～2700/3300～3800MHz
- 6/7/8/8
- ±45
Features:
Used in 2G/3G/4G/5G/WLAN system
Electrical specifications | ||||
Frequency range (MHz) | 617～697 | 698～960 | 1710～2700 | 3300～3800 |
Polarization | ±45° | |||
Gain (dBi) | 6 | 7 | 8 | 8 |
Typical Horizontal beam width (°) | 80 | 90 | 70 | 60 |
Typical Vertical beam width (°) | 80 | 80 | 60 | 40 |
Front-to-back ratio (dB) | 15 | 20 | 25 | 25 |
Isolation (dB) | ≥20 | ≥20 | ≥20 | ≥20 |
Impedance (Ω) | 50 | |||
VSWR | ≤2.0 | ≤1.8 | ||
Intermodulation IM3 (2×43dBm carrier) | / | ≤-150 dBc | ≤-150 dBc | / |
Maximum power (W) | 50 | |||
Lighting protection | DC Ground | |||
Mechanical specifications | |
Connector | 4*4.3-10 Female or 4* N Female |
Connector position | Bottom |
Exposed cable size (cm) | 30(or customer requirement) |
Height/width/depth (mm) | 410*305*84 |
Packing size (mm) | 425*425*118 |
Weight (kg) | ≤2.5(Include bracket) |
Radome material | ABS |
Radome color | White（RAL9003) |
Operating temperature (℃) | -40～60 |
Application | Outdoor |
Rated wind velocity (m/s) | 40 |
Suitable pole diameter (mm) | 130-400 |
Mounting kit | JM-VB8 |
