350～2700MHz Omnidirectional ceiling antenna
- TQJ-0327XDK
- 350～450/698～806/806～960/1710～2700MHz
- 2/3/6.5
- Vertical
Features:
Used in 2G/3G/4G/WLAN system
| Electrical specifications | ||||
| Frequency range (MHz) | 350～450 | 698～806 | 806～960 | 1710～2700 |
| Polarization | Vertical | |||
| Gain (dBi) | 2±1 | 3±1.5 | 6.5±1.5 | |
| Horizontal beam width (°) | 360 | |||
| Vertical beam width (°) | 85 | 60 | 30 | |
| Impedance (Ω) | 50 | |||
| VSWR | ≤2.5 | ≤2.2 | ≤1.8 | ≤1.8 |
| Maximum power (W) | 50 | |||
| Mechanical specifications | ||||
| Connector | N Female or customized | |||
| Exposed cable size (cm) | 15 or customized | |||
| Connector position | Bottom | |||
| Antenna size (mm) | （Φ320*175）±2 | |||
| Packing size (mm) | 273*273*274 | |||
| Weight (kg) | 0.6±0.1 | |||
| Radome material | ABS | |||
| Radome color | White | |||
| Operating temperature (℃) | -40～60 | |||
| Application | Indoor | |||
| Mounting | Nut | |||
