Adopt lumped structure, Small size

Low passband ripple, High isolation, Low insertion loss, Low VSWR

Easy to install

Suitable for indoor coverage system of cellular mobile communications and spread spectrum communications.


Specifications

Category

Dual-band Combiner

Model

HL-0825

Freq.Range -MHz

LF:824 to 960MHz    HF:1700 to 2500

Insertion Loss -dB

≤0.6

Isolation -dB

≥30

Nominal Impedance

50

VSWR

≤1.2

Power-W

20

Connector

SMA Female

Temperature -℃

-30 to +60

Relative Humidity -%

5 to 95

Dimensions -㎜

50×40×15

Weight -g

50
