350-6000MHz Power Splitter Series
350-6000MHz Power Splitter Series
- GFQ-2-03560B-4310F-W/GFQ-3-03560B-4310F-W/GFQ-4-03560B-4310F-W
- Others
- Splitters
- 350-6000
● Wide Frequency Band 350-6000MHz
● Tetra/2G/3G/4G/5G Coverage
● Low Passive Intermodulation(-155/-160dBc)
● Low VSWR & Insertion Loss
● Widely used for In-building Solutions
| Model | GFQ-2-03560B-4310F-W | GFQ-3-03560B-4310F-W | GFQ-4-03560B-4310F-W |
| Freq-MHz | 350-6000 | ||
| Output Ports | 2-way | 3-way | 4-way |
| Insertion Loss-dB | 350-3800MHz:≤3.3 | 350-3800MHz:≤5.2 | 350-3800MHz:≤6.5 |
| 3800-6000MHz: ≤3.5 | 3800-6000MHz: ≤5.6 | 3800-6000MHz: ≤7.0 | |
| VSWR | ≤1.35 | ≤1.4 | ≤1.5 |
| PIM-dBc | -155/-160@2*43dBm | ||
| Power-W | 200 | ||
| Impedance-Ω | 50 | ||
| Connector | 4.3-10 Female | ||
| Temp(deg) | -35~+75 | ||
| Application | Indoor & Outdoor IP65 | ||
| Colour | Black or Custom | ||
