Model | TQX-150A | TQX-150L | TQX-150SC |
Freq.Range-MHz | 134 to 173 | 134 to 173 | 156～162 |
Bandwidth-MHz | 6 | 8 | 6 |
Gain-dBi | 1.8 | 2 | 1.5 |
VSWR | ≤2 | ≤2.0 | ≤2.5 |
Impedance-Ω | 50 | 50 | 50 |
Polarization | Vertical | Vertical | Vertical |
Maximum Power-W | 30 | 30 | 30` |
Connector | BNC or TNC(add a T after the model when use TNC connector) | BNC male or TNC male | SMA-male |
Length-cm | 12 (vary with frequency) | 20 (vary with frequency) | 150±0.5 |
Weight－g | 45 (vary with frequency) | 30 (vary with frequency) | 7 |
