| KDP2-D4961E23BWA | |||
| Electrical Specifications | |||
| Frequency Range(MHz) | 4900-5150 | 5150-5500 | 5500-6100 |
| Polarization | Vertical and Horizontal | ||
| Gain(dBi) | 20.5 | 22 | 23 |
| Horizontal 3dB Beam_width(°) | 12 | 11 | 10 |
| Vertical 3dB Beam_width(°) | 12 | 11 | 10 |
| Front-to-Back Ratio (dB) | ≥28 | ||
| VSWR | ≤2.0 | ||
| Isolation (dB) | ≥28 | ||
| Impedance (Ω) | 50 | ||
| Maximum Power (W) | 50 | ||
| Lighting protection | DC ground | ||
| Mechanical Specifications | |||
| Connector | 2*N Female | ||
| Connector Position | Back | ||
| Dimensions(mm) | 315*315*15 | ||
| Radome/Color | ABS (white) | ||
| Antenna Weight(Kg) | 1 | ||
| Waterproof level | IP67 | ||
| Operating Temp(°C) | -40°C to +60°C | ||
| Wind resistance(m/s) | 55 | ||
| Salt spray resistance | JM-TA ,Support pole Φ30 to 50mm | ||
